Technology:
Carbon DLS
Applications:
Medical devices, wearables—e.g. wrist bands/head phones.
Description:
SIL 30 resin passed the requirements for biocompatibility tests so that they are suitable for prolonged skin contact (more than 30 days) and short-term mucosalmembrane contact (up to 24 hours). Tests performed: ISO 10993-5, Biological evaluation of medical devices - Part 5: Tests for in vitro cytotoxicity, and ISO 10993-10, Biological evaluation of medical devices - Part 10: Tests for irritation and skin sensitization (GPMT).
Features:
Soft touch, biocompatible, tear resistant
Color Options: Gray
| Property | ASTM | Metric Units |
|---|---|---|
| Tensile Properties, Die-C, 500 mm/min | ||
| Ultimate Tensile Strength | D412 | 3.4 MPa |
| Elongation at Break | D412 | 330 % |
| Stress at 50 % Elongation | D412 | 0.42 MPa |
| Stress at 100 % Elongation | D412 | 0.69 MPa |
| Stress at 200 % Elongation | D412 | 1.45 MPa |
| Mechanical Properties | ||
| Tear Strength | D624-C | 9.6 kN/m |
| General Properties | ||
| Hardness | D2240 | 35, Shore A |
