MPU 100

Technology:

Carbon DLS

Applications:

Medical capital equipment and single-use medical devices.

Description:

MPU 100 is a rigid plastic combining the properties of biocompatibility, mechanical strength, and sterilizability with abrasion and chemical resistance. Strong and durable enough for medical environments. Maintains biocompatibility post-sterilization. Sterilizable with ethylene oxide, e-beam, and gamma.

Features:

Production-ready, medical-grade polymer with engineering-grade mechanical properties. Compatible with cold sterilization techniques. Passes the following biocompatibility tests of ISO 10993-5, ISO 10993-10, and USP VI designation for plastics. Master file available with FDA. Certificate of Analysis is available upon request.

Color Options: White

Technical Data
Property ASTM Metric Units
Tensile Strength D638M 38 MPa
Modulus of Elasticity, Youngs Modulus D638M 1,200 MPa
Elongation at Break (%) D638M 25%
Flexural Strength D790M 44 MPa
Flexural Modulus D790M 1,000 MPa
IZOD Impact (notched) D256A 29 J/m
Heat Deflection Temperature@ 0.45 MPa/66 psi, (°C) D648 48° C
