Advanced functional prototypes, end-use parts.
FDM Technology uses the same tried and tested thermoplastics found in traditional manufacturing processes. ULTEM 9085 resin is a flame-retardant highperformance thermoplastic that makes applications that demand thermal and chemical resistance possible.
High performance. High strength-to-weight ratio. Exceptional FST (flame, smoke and toxicity) rating.
Color Options: Tan and Black
|Tensile Strength||D638M||33 MPa|
|Modulus of Elasticity, Youngs Modulus||D638M||2,270 MPa|
|Elongation Break (%)||D638M||2.2 %|
|Flexural Strength||D790M||68 MPa|
|Flexural Modulus||D790M||1,900 MPa|
|IZOD Impact Strength (notched)||D256A||48 J/m|
|Heat Deflection Temperature @ 0.45 MPa/66 psi, (ºC)||D648||153 °C|
