ProtoGen™ 18420

Description:

ProtoGen O-XT 18420 is a liquid, ABS-like, photopolymer that produces accurate parts ideal for general purpose applications. ProtoGen resins are the first SLA resins to demonstrate different material properties based on machine exposure control. 18420 offers superior chemical resistance, a wide processing latitude and excellent tolerance to a broad range of temperatures and humidities, both during and after build.

Applications:

This high-temperature, ABS-like photopolymer is used in the solid imaging process to build three-dimensional parts. 18420 provides considerable processing latitude and is ideal for the medical, electronic, aerospace and automotive markets that demand:

  • Accurate RTV patterns
  • Durable concept models
  • Highly accurate parts
  • Humidity and temperature tolerant parts
PROTOGEN 18420 ( UV POSTCURE AT HOC-2 )
Property ASTM Metric Units
Tensile Strength D638M 42.2-43.8 MPA
Tensile Modulus D638M 2,180-2,310%
Elongation at Break D638M 8-16%
Flexural Strength D790M 66.7-70.5 MPA
Flexural Modulus D790M 1,990-2,130 MPA
IZOD Impact, Notched D256A 0.20-0.22 J/CM
Hardness (Shore D) D2240 86-88
Water Absorption D570-98 0.68%
